XG-20cc-R Glow Gasoline Cav
XG-20CC-R
PROFESSIONAL GLOW-HOM
GASOLINE ENGINE
RAU AIRPLANE
Xa kev nug
Khoom Taw qhia
EPHIL
XG-20CC-R
PROFESSIONAL GLOW-HOM
GASOLINE ENGINE
RAU AIRPLANE
Precision Manufacturing
RPM ruaj khov
Linear Acceleration
Kev ua tau zoo
Yooj Yim Rau Kev Kho
Tsab ntawv "G" ntawm XG-series cav hais txog "Glow-type" engine. Raws li lub npe hu ua hluav taws xob cua sov cav.
Lub glow plug plays lub luag haujlwm tseem ceeb hauv kev ua kom lub cav ua haujlwm tau zoo los ntawm kev muab lub zog tsim nyog los ua kom muaj kev sib xyaw ntawm cov roj av thiab huab cua los ntawm kev tiv thaiv hlau cua sov. Qhov no ignition txoj kev teem lub cav sib nrug los ntawm cov tsis tu ncua (txias ntsaws ignition) roj av cav, muab nws txawv qhov zoo ntawm kev ua tau zoo thiab cov yam ntxwv.
COMPONENTS
| XG-20cc-S | XG-20cc-SPRO | XG-20cc-R | XG-20cc-RPRO | |
| Cav | √ | √ | √ | √ |
| Walbro Carburetor | √ | √ | √ | √ |
| Muffler Teeb (Sab Hom) | √ | √ | ||
| Muffler Set (Tom ntej) | √ | √ | ||
| Glow Plug | √ | √ | √ | √ |
| AET Power System | √ | √ | √ | √ |
| Cav Mount Set | √ | √ | √ | √ |
| Gear-Drive Propeller Hub | √ | √ | ||
| Lub cav pib | √ | √ | ||
| Pib ESC | √ | √ |
XG-20cc-R Standard Cheebtsam
XG-20cc-R ENGINE
Nrog Walbro Carb
Cav Muffler Set
E8
Glow Plug
AET Power System
(Lgnition Unit)
Cav Mount Set
Engine Operation Manual & Warranty Card
ephil et-power system
Ignition unit nrog tshiab ntse algorithm
Hloov pauv lub zog tso zis tswj tshuab
Tshiab tiam ignition rau lub glow plugs
Me me
Lub teeb nyhav
Tsawg EMI
Kev ruaj ntseg siab
Tsawg voltage
Kev siv hluav taws xob tsawg
Tsis muaj Ignition Timing
Tsis muaj Ignition Angle
PARAMETERS
Qauv: XG-20cc-R
Kev xa tawm: 20cc (1.22 cu hauv)
Peev xwm: 2.4 HP
Kev nrawm nrawm: 2000-8300 RPM (Test Propeller-16*8)
Loj: 32mm (1.26 nti)
Stroke: 27mm (1.06 nyob rau hauv)
Static Thrust: 6.7 kg @ 100 m ALT (14.8 lb @ 328 ft ALT)
Static Thrust: 5.2 kg @ 1800 m ALT (11.5 lb @ 5900 ft ALT)
Compression ratio: 9: 1
Lubrication piv: 30: 1 ( Roj: 2-Stroke Tsav Roj)
Ignition Voltage: 6-8.4V
Glow Plug Hom: E8 (los yog OS G5) Glow Plug & AET Fais Fab System
Pom zoo Propeller: 16x8; 14x10; 15 x 8; 16 x 6; 17x6 ib
Qhov hnyav ntawm lub cav loj: 697g
Qhov hnyav ntawm Muffler Teeb: 62g
Qhov hnyav ntawm Cav Mount Teeb: 115g
Qhov hnyav ntawm Glow Plug: 3.6g
Qhov hnyav ntawm AET (Ignition): 30g
Qhov hnyav tag nrho: 908g (2.0 lb)
Cim npe nrov: xg-20cc-r glow roj av cav, Tuam Tshoj xg-20cc-r glow roj av cav manufacturers, lwm tus neeg, Hoobkas
